3.5 Modbus data tables
SIMOCODE pro - Communication
286 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Input/holding
register
Type
Discrete
input / coil
address
Identifier
Access
1)
Address
high/low
0x1C97
Warning - EM+ short circuit
r
high Bit
0x1C98
Warning - Warning I>
r
0x1C99 Warning - Warning I< r
0x1C9A
Warning - Warning P>
r
0x1C9B
Warning - Warning P<
r
0x1C9C
Warning - Warning cos phi<
r
0x1C9D
Warning - Warning U<
r
0x1C9E
Warning - Warning 0/4 - 20mA>
r
0x1C9F
Warning - Warning 0/4 - 20mA<
r
0x1C0A
low Bit
0x1CA0
Warning - Stalled rotor
r
0x1CA1
Reserved
r
0x1CA2
Reserved
r
0x1CA3
Warning - No start possible
r
0x1CA4
Warning - Number of starts >
r
0x1CA5
Warning - Just one start possible
r
0x1CA6
Warning - Motor operating hours>
r
0x1CA7
Warning - Motor stop time >
r
high Bit
0x1CA8
Warning - External fault 1
r
0x1CA9
Warning - External fault 2
r
0x1CAA
Warning - External fault 3
r
0x1CAB
Warning - External fault 4
r
0x1CAC Warning - External fault 5 r
0x1CAD
Warning - External fault 6
r
0x1CAE
Reserved warning - External fault 7
r
0x1CAF
Reserved warning - External fault 8
r
0x1C0B
low Bit
0x1CB0
Warning - AM1 open circuit
r
0x1CB1
Warning - DM-F safety-related tripping
r
0x1CB2
Warning - DM-F test requirement
r
0x1CB3
Reserved
r
0x1CB4
Reserved
r
0x1CB5
Reserved
r
0x1CB6
Warning - DM-F feedback circuit
r
0x1CB7
Warning - DM-FL simultaneity
r
high Bit
0x1CB8
Fault - HW fault basic unit
r
0x1CB9
Fault - Module fault
r
0x1CBA
Fault - Temporary components
r
0x1CBB
Fault - Configuration error
r
0x1CBC
Fault - Parameterization
r
0x1CBD
Fault - Bus
r
0x1CBE
Fault - PLC/PCS
r
