3.5 Modbus data tables
SIMOCODE pro - Communication
306 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Input/holding register
Designation
Type
Range
Unit
Default
Comments
Access
1)
Info
Address
high/
low
Bit
2-3 Non-volatile
element 4 - type
Bit[2] 0, 1, 2, 3 0
with memory
r
4-5 Calculator 2 -
Operator
Bit[2] 0, 1, 2, 3 0 r
6-7 Reserved Bit[2] 0 r
low
0-1
Reserved
Bit[2]
0
r
2-3
Reserved
Bit[2]
0
r
4-5 OPD - Operator
panel
display (bit 0 ... 1)
Bit[2] 0 ... 4 2 0 = Manual
1 = 3 s
2 = 10 s
3 = 1 min
4 = 5 min
r from E03
6-7 OPD - Operator
panel
display (bit 2 ... 3)
Bit[2] r
Part - Bit[4]
parameters
r
0x438E high 0-2 TM1 - sensor type Bit[3] 000B to
100B
000B 000B = PT100
001B = PT1000
010B = KTY83
011B = KTY84
100B = NTC
r
Reserved
Bit
r
4-7
OPD - Language
Bit[4]
0 ... 15
0
r
from E03
low 0-3 Reset response
external fault 5
Bit[4] 0 ...
1111B
0101B Bit[0] = Panel
reset
Bit[1] = Auto
reset
Bit[2] = Remote
reset
Bit[3] = OFF
command reset
r
4-7 Reset response
external fault 6
Bit[4] 0 ...
1111B
0101B r
0x438F high 0-3 OPD -
Contrast (bit 0 ... 3)
Bit[4] 0 ... 255 1 % 50 r from E03
4-7 OPD -
Contrast (bit 4 ... 7)
Bit[4] r
low 0-3 OPD -
Profile (bit 0 ... 3)
Bit[4] 0 ... 33 0 r
4-7 OPD -
Profile (bit 4 ... 7)
Bit[4] r
0x4390 high 0-3 Truth table 7 type
2I/1O
Bit[4] 0 ...
1111B
0 r
4-7 Truth table 8 type
2I/1O
Bit[4] 0 ...
1111B
0 r
