3.5 Modbus data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
307
Input/holding register
Designation
Type
Range
Unit
Default
Comments
Access
1)
Info
Address
high/
low
Bit
low 0-3 Is1 conversion
factor - Denominator
Bit[4] 0 ... 15 0 r
4-7 Is2 conversion
factor - Denominator
Bit[4] 0 ... 15 0 r
0x4391 high 0-3 Hysteresis P -
cos phi - U
Bit[4] 0 ... 15 1 % 5 r
4-7 Hysteresis 0/
4-20 mA
Bit[4] 0 ... 15 1 % 5 r
low
0-3
Hysteresis free limits
Bit[4]
0 ... 15
1 %
5
r
4-7 OPD - Lighting Bit[4] 0 ... 4 2 0 = OFF
1 = 3 s
2 = 10 s
3 = 1 min
4 = 5 min
r from E03
Part - Byte
parameters
0x4392
high
Byte
r
low EM - Delay Byte 0 ... 255 100
ms
5 r/w EM
0x4393 high Trip level cos phi< Byte 0 ... 100 1 % 0 r/w UM
low Warning
level cos phi<
Byte 0 ... 100 1 % 0 r/w UM
0x4394 high Trip level U< Byte 0 ... 255 8 V 0 r/w UM
low Warning level U< Byte 0 ... 255 8 V 0 r/w UM
0x4395 high Trip level 0/
4-20 mA>
Byte 0 ... 255 *128 0 r/w AM1
low Warning level 0/
4-20mA>
Byte 0 ... 255 *128 0 r/w AM1
0x4396 high Trip level 0/
4-20 mA<
Byte 0 ... 255 *128 0 r/w AM1
