Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
317
Instance 100: Output assembly SIMOCODE basic type 1
The table below describes the format of attribute 3:
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Cycl.
receive
byte 0 -
bit 0.7
Cycl.
receive
byte 0 -
bit 0.6
Cycl.
receive
byte 0 -
bit 0.5
Cycl.
receive
byte 0 -
bit 0.4
Cycl.
receive
byte 0 -
bit 0.3
Cycl.
receive
byte 0 -
bit 0.2
Cycl.
receive
byte 0 -
bit 0.1
Cycl.
receive
byte 0 -
bit 0.0
1 Cycl.
receive
byte 1 -
bit 1.7
Cycl.
receive
byte 1 -
bit 1.6
Cycl.
receive
byte 1 -
bit 1.5
Cycl.
receive
byte 1 -
bit 1.4
Cycl.
receive
byte 1 -
bit 1.3
Cycl.
receive
byte 1 -
bit 1.2
Cycl.
receive
byte 1 -
bit 1.1
Cycl.
receive
byte 1 -
bit 1.0
2 ... 3
Cycl. receive byte 2/3 - analog value 1
The values passed to SIMOCODE pro via instance 100 can be processed further in the
SIMOCODE ES (TIA Portal) software.
Corresponding function blocks in the SIMOCODE ES (TIA Portal) charts:
Default settings of cyclic receive and send data: See Assignment of cyclic receive and send
data for predefined control functions (Page 128).

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
