Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
323
Instance 152: Input assembly SIMOCODE basic type 3
The table below describes the format of attribute 3:
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Cycl. send
byte 0 -
bit 0.7
Cycl. send
byte 0 -
bit 0.6
Cycl. send
byte 0 -
bit 0.5
Cycl. send
byte 0 -
bit 0.4
Cycl. send
byte 0 -
bit 0.3
Cycl. send
byte 0 -
bit 0.2
Cycl. send
byte 0 -
bit 0.1
Cycl. send
byte 0 -
bit 0.0
1 Cycl. send
byte 1 -
bit 1.7
Cycl. send
byte 1 -
bit 1.6
Cycl. send
byte 1 -
bit 1.5
Cycl. send
byte 1 -
bit 1.4
Cycl. send
byte 1 -
bit 1.3
Cycl. send
byte 1 -
bit 1.2
Cycl. send
byte 1 -
bit 1.1
Cycl. send
byte 1 -
bit 1.0
2 ... 3
Cycl. send byte 2/3 - analog value 1
Cycl. analog float input 1
4 ... 5
Cycl. send byte 4/5 - analog value 2
6 ... 7
Cycl. send byte 6/7 - analog value 3
Cycl. analog float input 2
8 ... 9
Cycl. send byte 8/9 - analog value 4
10 ... 11
Cycl. send byte 8/9 - analog value 5
Cycl. analog float input 3
12 ... 13
Cycl. send byte 8/9 - analog value 6
14 ... 15
Cycl. send byte 8/9 - analog value 7
Cycl. analog float input 4
16 ... 17
Cycl. send byte 8/9 - analog value 8
18 ... 19
Cycl. send byte 8/9 - analog value 9
The bit and analog values signaled by SIMOCODE pro to the control system via
instance 152 can be freely assigned in the SIMOCODE ES (TIA Portal) software.
Corresponding function blocks in the SIMOCODE ES (TIA Portal) charts:
