Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
325
Instance 153: Input assembly SIMOCODE basic type 4
The table below describes the format of attribute 3:
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Cycl. send
byte 0 -
bit 0.7
Cycl. send
byte 0 -
bit 0.6
Cycl. send
byte 0 -
bit 0.5
Cycl. send
byte 0 -
bit 0.4
Cycl. send
byte 0 -
bit 0.3
Cycl. send
byte 0 -
bit 0.2
Cycl. send
byte 0 -
bit 0.1
Cycl. send
byte 0 -
bit 0.0
1 Cycl. send
byte 1 -
bit 1.7
Cycl. send
byte 1 -
bit 1.6
Cycl. send
byte 1 -
bit 1.5
Cycl. send
byte 1 -
bit 1.4
Cycl. send
byte 1 -
bit 1.3
Cycl. send
byte 1 -
bit 1.2
Cycl. send
byte 1 -
bit 1.1
Cycl. send
byte 1 -
bit 1.0
2 ... 3
Cycl. send byte 2/3 - analog value 1
Cycl. analog float input 1
4 ... 5
Cycl. send byte 4/5 - analog value 2
6 ... 7
Cycl. send byte 6/7 - analog value 3
Cycl. analog float input 2
8 ... 9
Cycl. send byte 8/9 - analog value 4
10 ... 11
Cycl. send byte 8/9 - analog value 5
Cycl. analog float input 3
12 ... 13
Cycl. send byte 8/9 - analog value 6
14 ... 15
Cycl. send byte 8/9 - analog value 7
Cycl. analog float input 4
16 ... 17
Cycl. send byte 8/9 - analog value 8
18 ... 19
Cycl. send byte 8/9 - analog value 9
20 ... 259
Data of the Measurement object: See Measurement object (Page 329).
260 ... 487
Data of the Statistical Data object: See Statistical Data object (Page 331).
The bit and analog values signaled by SIMOCODE pro to the control system via
instance 153 can be freely assigned in the SIMOCODE ES (TIA Portal) software.
Corresponding function blocks in the SIMOCODE ES (TIA Portal) charts:
