Siemens SIMOCODE pro Function Manual

Communication
2.2 PROFINET communication
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
73
Combination of ChannelProperties.Qualifier (bit 9/10) and ChannelProperties.Specifier
(bit 11/12) (continued)
Maintenance
Required Bit 9
Maintenance
Demanded Bit 10
Specifier
Bit 12/11
Meaning
Diagnostics in user programs
SIMATIC S7 300 and
SIMATIC S7 400
1 0
00
Reserved
-
01 Maintenance demand is active Evaluation of diagnostic interrupts
with SFB54 in the OB82 read data
records with SFB52
10 Maintenance demand no longer
active
Evaluation of diagnostic interrupts
with SFB54 in the OB82
11 Maintenance demand no longer
active - all others still active
1 1
00
Reserved
-
01 Graded diagnostics is active Evaluation of diagnostic interrupts
with SFB54 in the OB82 read data
records with SFB52
10
Graded diagnostics no longer active
Evaluation of diagnostic interrupts
with SFB54 in the OB82
11 Graded diagnostics no longer active
- all others still active
Data block "ChannelProperties.Specifier (Bit 11/12)"
Table 2- 23 ChannelProperties.Specifier (bit 11/12)
Value
Meaning
Diagnostics in user programs SIMATIC S7 300
and SIMATIC S7 400
00
Reserved
-
01 Pending diagnostics Evaluation of diagnostic interrupts with SFB54 in
the OB82 read data records with SFB52
10
Cleared event and no further events
Evaluation of diagnostic interrupts with SFB54 in
the OB82
11
Cleared events, but other events remain
Data block "ChannelProperties.Direction (bits 13 - 15)"
Table 2- 24 ChannelProperties.Direction (bit 13 - 15)
Value
Meaning
000
Manufacturer-specific
001
Input
010 Output
011
Input/Output
100 - 111 Reserved

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
