Button Short name Description
MAN-Obstacles Switch between the blocked regions for SAM and MAN mode.
Help
Function description of the keys for scrolling and zooming in the
diagram display.
Note
The buttons for operating the x/y diagram are explained in Chapter x/y diagram (Page 304).
Print, print preview - F6 (Print)
The diagram can be printed using the "F6-Print" button. After selecting the printer and the
printer settings, a print preview appears when the "OK" button is pressed to confirm. Various
details (e.g. print with/without legend) can be set in this print preview. Zooming with the mouse
is also possible.
Figure 8-36 Print, print preview function
SIMOCRANE CeCOMM commissioning and diagnostic program
8.7 Diagram - trace function
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 301
