Table 3-19 FB_CommonPLCToAddOn connections
Name Type Data
type
Unit-global variables of "AddOn" Meaning
Common_IO_PIW IN ARRAY
[0..11]
OF word
addon_common_receive Input array for the Common
block (see Figure 5-13 Ad‐
dress list in SCOUT (commu‐
nication between SIMATIC
S7 and SIMOTION)
(Page 122))
b16_stw1 OUT WORD - Control word 1 output not sep‐
arated into individual bits
bo_stw_1_Man_Fixobst_Off OUT BOOL common_plc_man_fixobst_off Bit 0 of control word 1
bo_stw_1_Man_Varobst_Off OUT BOOL common_plc_man_varobst_off Bit 1 of control word 1
bo_stw1_No_Wait_Pos OUT BOOL common_plc_no_wait_pos Bit 2 of control word 1
bo_stw1_Hoist_Man OUT BOOL common_plc_hoist_man Bit 3 of control word 1
bo_stw1_Locked_Bit0 OUT BOOL common_plc_locked_bit0 Bit 4 of control word 1
bo_stw1_Locked_Bit1 OUT BOOL common_plc_locked_bit1 Bit 5 of control word 1
bo_stw1_Slackrope OUT BOOL common_plc_slackrope Bit 6 of control word 1
bo_stw1_Bayscanner_Valid OUT BOOL common_plc_bayscanner_valid Bit 7 of control word 1
bo_STW1_Learn_Profil_On OUT BOOL common_plc_learn_profil_on Bit 8 of control word 1
bo_STW1_Learn_Profil_Reset OUT BOOL common_plc_learn_profil_reset Bit 9 of control word 1
bo_stw1_Dig_Hoist_Dist_Corr OUT BOOL common_plc_dig_hoist_dist_corr Bit 10 of control word 1
bo_stw1_Start_2D_Calc OUT BOOL common_plc_start_2d_calc Bit 11 of control word 1
bo_STW1_Spreaders_Coupled OUT BOOL common_plc_Spreaders_Coupled Bit 12 of control word 1
bo_stw1_impnt_ext_active OUT BOOL common_plc_Impnt_Ext_Active Bit 13 of control word 1
bo_stw1_save_logger OUT BOOL common_plc_Save_Logger Bit 14 of control word 1
i16Load OUT INT common_plc_load Weight of the load
i32Value_Bayscanner OUT DINT common_plc_value_bayscanner Bay scanner value
i32Count_Bayscanner OUT DINT common_plc_count_bayscanner Bay scanner counter
i8ParSet OUT SINT common_plc_ParSet Parameter set
i16DS_Width OUT INT common_plc_DS_Width Overall width in double-
spreader operation
i32impnt_ext OUT DINT common_plc_Impnt_Ext External immersion point
from PLC
Task
The "FB_CommonPLCToAddOn" block reads the input area from the PROFIBUS DP /
PROFINET PN for the Common block and separates the array into words and bits.
Connections
The outputs must be connected using unit-global variables of the "AddOn" MCC source file with
the inputs of the DCC_SCCOMMON DCC block.
Overview of the software
3.3 Sway control function blocks
SC integrated STS, GSU
Operating Instructions, 07/2019, A5E48271265B AA 59
