Task
The "FB_TrolleyPLCToAddOn" block reads the input area from the PROFIBUS DP /
PROFINET PN for the Trolley block and separates the array into words and bits.
Connections
The outputs must be connected using unit-global variables of the "AddOn" MCC source file with
the inputs of the DCC_SCTROLLEY DCC block.
Table 3-23 FB_TrolleyPLCToAddOn connections
Name Type Data
type
Unit-global variables of "AddOn" Meaning
Trolley_IO_PIW IN ARRAY
[0..5] OF
word
addon_trolley_receive Input array for the Trolley
block (see Figure 5-13 Ad‐
dress list in SCOUT (commu‐
nication between SIMATIC
S7 and SIMOTION)
(Page 122))
b16_stw1 OUT WORD Control word 1 output not sep‐
arated into individual bits
bo_stw1_Release OUT BOOL trolley_plc_release Bit 0 of control word 1
bo_stw1_Travel OUT BOOL trolley_plc_travel Bit 1 of control word 1
bo_stw1_OM_Pos OUT BOOL trolley_plc_om_pos Bit 2 of control word 1
bo_stw1_OM_Speed OUT BOOL trolley_plc_om_speed Bit 3 of control word 1
bo_stw1_OM_Load_Pos OUT BOOL trolley_plc_om_load_pos Bit 4 of control word 1
bo_stw1_OM_Trolley_Pos OUT BOOL trolley_plc_om_trolley_pos Bit 5 of control word 1
bo_stw1_OM_Hoist_Control OUT BOOL trolley_plc_om_hoist_control Bit 6 of control word 1
bo_stw1_SC_ON OUT BOOL trolley_plc_sc_on Bit 7 of control word 1
bo_stw1_LS_FW OUT BOOL trolley_plc_ls_fw Bit 8 of control word 1
bo_stw1_LS_BW OUT BOOL trolley_plc_ls_bw Bit 9 of control word 1
bo_stw1_PreLS_FW OUT BOOL trolley_plc_prels_fw Bit 10 of control word 1
bo_stw1_PreLS_BW OUT BOOL trolley_plc_prels_bw Bit 11 of control word 1
bo_stw1_Brake_closed OUT BOOL trolley_plc_brake_closed Bit 12 of control word 1
bo_stw1_SC_When_Stop OUT BOOL trolley_plc_sc_when_stop Bit 13 of control word 1
bo_stw1_Controlled_Stop OUT BOOL trolley_plc_controlled_stop Bit 14 of control word 1
bo_stw1_Flying OUT BOOL trolley_plc_flying Bit 15 of control word 1
i16Override OUT INT trolley_plc_override PLC override
i16Offset OUT INT trolley_plc_offset Position offset from PLC
Overview of the software
3.3 Sway control function blocks
SC integrated STS, GSU
64 Operating Instructions, 07/2019, A5E48271265B AA
