Connections
The outputs can be further interconnected using the unit-global variables of the "AddOn" MCC
source file. No unit-global variables are created for unused outputs.
Table 3-33 FB_AddDataPLCToAddOn connections
Name Type Data type Unit-global variables of "AddOn" Meaning
AddData1_IO_PIW IN AR‐
RAY[0..15]
OF WORD
Input array for additional data
(see Figure 5-13 Address list
in SCOUT (communication
between SIMATIC S7 and SI‐
MOTION) (Page 122))
AddData2_IO_PIW IN AR‐
RAY[0..15]
OF WORD
AddData3_IO_PIW IN ARRAY[0..5]
OF WORD
b16AddData1_Word1 OUT WORD Not connected
b16AddData1_Word2 OUT WORD Not connected
b16AddData1_Word3 OUT WORD Not connected
b16AddData1_Word4 OUT WORD Not connected
b16AddData1_Word5 OUT WORD Not connected
b16AddData1_Word6 OUT WORD Not connected
b16AddData1_Word7 OUT WORD Not connected
b16AddData1_Word8 OUT WORD Not connected
b16AddData1_Word9 OUT WORD Not connected
b16AddData1_Word10 OUT WORD Not connected
b16AddData1_Word11 OUT WORD Not connected
b16AddData1_Word12 OUT WORD Not connected
b16AddData1_Word13 OUT WORD Not connected
b16AddData1_Word14 OUT WORD Not connected
b16AddData1_Word15 OUT WORD Not connected
b16AddData1_Word16 OUT WORD Not connected
b16AddData2_Word1 OUT WORD Not connected
b16AddData2_Word2 OUT WORD Not connected
b16AddData2_Word3 OUT WORD Not connected
b16AddData2_Word4 OUT WORD Not connected
b16AddData2_Word5 OUT WORD Not connected
b16AddData2_Word6 OUT WORD Not connected
b16AddData2_Word7 OUT WORD Not connected
b16AddData2_Word8 OUT WORD Not connected
b16AddData2_Word9 OUT WORD Not connected
b16AddData2_Word10 OUT WORD Not connected
b16AddData2_Word11 OUT WORD Not connected
b16AddData2_Word12 OUT WORD Not connected
b16AddData2_Word13 OUT WORD Not connected
b16AddData2_Word14 OUT WORD Not connected
Overview of the software
3.3 Sway control function blocks
SC integrated STS, GSU
76 Operating Instructions, 07/2019, A5E48271265B AA
