System
7.3 PLC diagnosis represented as a ladder diagram
7-118
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Search options:
S Search for absolute and symbolic operands
S Go to line
Search criteria:
S Down (from the current cursor position)
S Whole program block (from the beginning)
Fig. 7-51 Searching for operands in cross references
The text you are looking for is displayed in the notes line. If the text is not found, an ap-
propriate error message is displayed which must be confirmed with <OK>.
If the search object is found, use the <Continue search> softkey to continue the search.
