Introduction
1.3 Accessibility options
1-17
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Q Square root function
The X value in front of the input cursor is replaced by the X
2
value.
R Square root function
The X value in front of the input cursor is replaced by the √X value.
( ) Bracket function (X+Y)*Z
Calculation examples
Task Input –> Result
100 + (67*3) 100+67*3 –> 301
sin(45_) 45 S –> 0.707107
cos(45_) 45 O –> 0.707107
4
2
4 Q –> 16
√4 4 R –> 2
(34+3*2)*10 (34+3*2)*10 –> 400
To calculate auxiliary points on a contour, the calculator offers the following functions:
S Calculating the tangential transition between a circle sector and a straight line
S Moving a point in the plane
S Converting polar coordinates to Cartesian coordinates
S Adding the second end point of a straight line/straight line contour section given from an
angular relation
1.3.2 Editing Chinese characters
This function is only available in the Chinese language version.
The control system provides a function for editing Chinese characters in the program editor
and in the PLC alarm text editor. After activation, type the phonetic alphabet of the searched
character in the input field. The editor offers various characters for this sound, from which
you can choose the desired one by entering either of the digits 0 to 9.
Fig. 1-5 Chinese editor
<ALT + S> Use this key combination to turn on / off the editor
