1-11
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Introduction
1.1 Screen layout
Status area
Application area
Tip
and softkey area
G
function
ÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
ÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
ÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
ÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
ÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
Fig. 1-1 Screen layout
The screen is divided into the following main areas:
S Status area
S Application area
S Tip and softkey area
1
