AUTOMATIC Mode
5.4 Reapproach after cancellation
5-63
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
5.4 Reapproach after cancellation
After a program cancellation (RESET), you can retract the tool from the contour in the Ma-
nual mode (JOG).
Operating sequence
Select the AUTOMATIC mode.
Use this softkey to open the “Block search” window for loading the interruption point.
The interruption point is loaded.
Selecting this softkey starts the block search to the interruption point. An adjustment to the
start position of the interrupted block is carried out.
Press <NC START> to continue the program execution.
5.5 Repositioning after interruption
After a program interruption (NC STOP), you can retract the tool from the contour in the Ma-
nual mode JOG; The control system saves the coordinates of the point of interruption. The
distances traversed by the axes are displayed.
Operating sequence
Select the AUTOMATIC mode.
Press <NC START> to continue the program execution.
Caution
When reapproaching the interruption point, all axes will traverse at the same time. Make
sure that the traversing area is not obstructed.
Block
search
Interr.
To
contour
