Manually Controlled Mode
4.2 MDA mode (Manual Data Input) “Machine” operating area
4-52
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Use this softkey to switch between the metric and the inch dimension systems.
4.2 MDA mode (Manual Data Input) “Machine” operating area
Functionality
In the MDA mode, you can create or execute a part program.
!
Caution
The Manual mode is subject to the same safety interlocks as the fully automatic mode.
Furthermore, the same prerequisites are required as in the fully automatic mode.
Operating sequences
Use the MDA key on the machine control panel to select the <MDA> mode.
Fig. 4-4 MDA start screen
Enter one or several blocks using the keyboard.
Press <NC START> to start machining. During machining, editing of the blocks is no longer
possible.
The contents are stored even after editing. After restarting the NC, the axes can be tra-
versed.
Switch
mm>inch
