Manually Controlled Mode
4.2 MDA mode (Manual Data Input) “Machine” operating area
4-53
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Parameters
Table 4-2 Description of the parameters in the MDA working window
Parameter
Explanation
MCS
X
Y
C1
C2
Displays the existing axes in the MCS or WCS
+X
...
–Y
If you traverse an axis in the positive (+) or negative () direction, a plus or minus sign will appear in
the relevant field.
If the axis is already in the required position, no sign is displayed.
Position
mm
These fields display the current position of the axes in the MCS or WCS.
Distance-
to-go
This field displays the distance to go of the axes in the MCS or WCS.
G function Displays important G functions
Feedrate F Displays the path feedrate actual value and setpoint in mm/min or mm/rev.
Tool Displays the currently active tool with the current edge number (T..., D...).
Editing win-
dow
In the “Reset” program state, an editing window serves to input a part program block.
Softkeys
Refer to Section 4.1
The G function window displays G functions whereby each G function is assigned to a group
and has a fixed position in the window.
Use the <Page Down> and <Page Up keys> to display further G functions. Selecting the
softkey repeatedly will close the window.
Displays all G functions.
This window displays the auxiliary and M functions currently active. Selecting the softkey
repeatedly will close the window.
Use this softkey to display the Axis feedrate
window. Selecting the softkey repeatedly will close the window.
Use this function to delete blocks from the program window.
Enter a name in the input field with which you wish the MDA program to be saved in the pro-
gram directory. Alternatively, you may select an existing program from the list.
Use the TAB key to change between input field and program list.
Settings
G
function
All G
funct.
Auxiliary
function
Axis
feedrate
Delete
MDA progr.
Save
MDA progr.
