Manually Controlled Mode
4.2 MDA mode (Manual Data Input) “Machine” operating area
4-54
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Fig. 4-5
The actual values for the MDA mode are displayed depending on the selected coordinate
system. Use this softkey to switch between the two coordinate systems.
MCS-WCS-
REL
