Programming
8-134
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Address ProgrammingInformationValue assignmentsMeaning
MCALL Modal subroutine call – The subroutine in the block containing MCALL is
called automatically after each successive block
containing a path motion. The call acts until the next
MCALL is called.
Application example: Drilling a hole pattern
N10 MCALL CYCLE82(...) ; Separate block, drilling
cycle
N20 HOLES1(...) ; Row of holes
N30 MCALL ; Separate block, modal
; Call of CYCLE82(...) comp.
MSG () Message max. 65 characters Message text in inverted commas N10 MSG(“MESSAGE TEXT”) ; Separate block
...
N150 MSG() ; Cancel previous message
RP Polar radius 0.001 ... 99 999.999 Traversing in polar coordinates, pole specification; in
addition: Polar angle AP
see G0, G1, G2; G3
G110, G111, G112
RPL Angle of rotation with
ROT, AROT
0.00001 ... 359.9999 Specification in degrees; angle for a programmable
rotation in the current plane G17 to G19
see ROT, AROT
PON Punching ON Activates the punching function and deactivates SON;
Stroke is only initiated at the end-of-block point
PONS Punching ON, activated in
the position controller
As with PON, but triggered in the position control cycle
PDELAYON Delay when punching ON
PDELAYOF * Delay when punching
OFF
SON Nibbling ON Activates the nibbling function and deactivates PON;
first stroke is performed at the starting point of the
activated block
SONS Nibbling ON, activated in
the position controller
The same behavior as SON, but triggered in the
position control cycle
SPIF1 * First punching interface
active
Fast NCK inputs/outputs for punching/nibbling byte 1
SPOF * Punching/nibbling OFF Quits all punching/nibbling functions
SPN Number of path sections
per block (stroke/punch
number)
Automatic path segmentation into the programmed
number of path segments
SPP Length of path section
(stroke/punch path)
Divides the programmed total path automatically into
path segments of equal length according to the
programmed distance to be traversed
SET( , , , )
REP()
Set values for the
variable fields
SET: Various values, from the specified element
up to: according to the number of values
REP: the same value, from the specified element up to
the end of the field
DEF REAL VAR2[12]=REP(4.5)
; All elements with value 4.5
N10 R10=SET(1.1,2.3,4.4)
; R10=1.1, R11=2.3, R4=4.4
