Part Programming
6.2 Editing part programs “Program” operating area
6-70
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Softkeys
Use this softkey to edit text.
Use this softkey to execute the selected file.
Use this softkey to select a text segment up to the current cursor position using the arrow
keys.
Use this softkey to copy a selected block to the clipboard.
Use this softkey to paste a text from the clipboard at the current cursor position.
Use this softkey to delete a selected text.
Use the Find softkey to search for a string in the program file displayed.
Type the term you are looking for in the input line and use the <OK> softkey to start the
search.
Use “Abort” to close the dialog box without starting the search process.
Use this softkey to replace the block numbers from the current cursor position up to the pro-
gram end.
The simulation is described in Section 6.3.
For recompilation, position the cursor on the cycle calling line in the program. This function
decodes the cycle name and prepares the screenform with the relevant parameters. If there
are any parameters beyond the range of validity, the function will automatically use the de-
fault values. After closing the screenform, the original parameter block is replaced by the
corrected block.
Note: Only automatically generated blocks can be recompiled.
Edit
Run
Select
block
Copy
block
Paste
block
Delete
block
Find
Number
Simulation
Recompile
