Part Programming
6.3 Simulation
6-77
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Elongated hole punch form
Use the Length and Width input fields to define the dimensions of the elongated hole.
The rounding radius results from the ratio between length and width.
Fig. 6-14 Elongated hole punch form
Double “D” punch form
Use the Width input field to define the dimensions of the Double “D” punch form.
The rounding radius always corresponds to the radius of the envelope circle.
Fig. 6-15 Double “D” punch form
