Siemens SINUMERIK 802D sl Operation And Programming Manual

External machine control panel
ix
SINUMERIK 802D sl Operation and Programming Nibbling (BP-N), 06/2006 Edition
6FC5 398-3CP10-0BA0
Numeric keys
Double assignment on the Shift level
External machine control panel
0
2
6
10
20
40
60
70
80
120
110
100
90
100
60
110
70
80
90
120
RESET
NC STOP
NC START
EMERGENCY STOP
%
Spindle override (option)
User-defined key with LED
User-defined key without LED
INCREMENT
Incremental dimension
JOG
REFERENCE POINT
Reference point
AUTOMATIC
SINGLE BLOCK
MANUAL DATA
Manual input
SPINDLE START LEFT
Spindle CCW rotation
SPINDLE STOP
SPINDLE START RIGHT
Spindle CW rotation
RAPID TRAVERSE OVERLAY
Rapid traverse override
X axis
Z axis
%
Feedrate override
