4.9 Drive data
4-139
 Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
5160 PISTON_POS_MIN_NAT_FREQ Cross reference: -
Min. natural frequency piston position Related to:
HLA
Protection level:
3/3
Unit:
mm
Default:
0.0
Minimum:
0.0
Maximum:
3000.0
Data type:
FLOAT
Active:
Immediately
5161 DRIVE_DAMPING Cross reference: -
Drive damping Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0.1
Minimum:
0.01
Maximum:
1.0
Data type:
FLOAT
Active:
Immediately
5162 DRIVE_NATURAL_FREQUENCY_A Cross reference: -
Natural frequency of drive A Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
1.0
Minimum:
1.0
Maximum:
2000.0
Data type:
FLOAT
Active:
Immediately
5163 DRIVE_NATURAL_FREQUENCY Cross reference: -
Natural frequency of drive Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
1.0
Minimum:
1.0
Maximum:
2000.0
Data type:
FLOAT
Active:
Immediately
5164 DRIVE_NATURAL_FREQUENCY_B Cross reference: -
Natural frequency of drive B Related to:
HLA
Protection level:
3/3
Unit:
Hz
Default:
1.0
Minimum:
1.0
Maximum:
2000.0
Data type:
FLOAT
Active:
Immediately
5180 CLOSED_LOOP_SYSTEM_DAMPING Cross reference: -
Selected damping for closed-loop system Related to:
HLA
Protection level:
3/3
Unit:
-
Default:
0.7
Minimum:
0.2
Maximum:
1.0
Data type:
FLOAT
Active:
Immediately
corresponds to: MD 5414, MD 5415, MD 5431, MD 5433
The drive is approximated as a PT2 low pass for the purpose of dimensioning
the closed-loop velocity control. The characteristic values “natural frequency”
and “damping” are calculated and preset from other drive data by the “Calculate
drive model data” function.
With MD 5180: CLOSED_LOOP_SYSTEM_DAMPING can be set to specify the
degree of damping to be applied in calculating the control loop during “Calculate
controller data”.
Example: Damping of 0.9
Slow closed-loop system with infrequent overshoots
Damping of 0.5
Fast closed-loop system with frequent overshoots
Dynamic drive
model data
4 Firmware Drive Functions

Siemens Sinumerik 840D Series Specifications

General

Axes	Up to 31 axes
Power Supply	24 V DC
Control Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
PLC	Integrated PLC (programmable logic controller)
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Max. Number of Channels	Up to 10 channels
