10.03
2.2 Integration in SINUMERIK 840D/SIMODRIVE 611 digital
2-25
Siemens AG, 2003. All rights reserved
SINUMERIK 840D/SIMODRIVE 611 digital, HLA Module (FBHLA) - 10.03 Edition
Table 2-1 Components of SINUMERIK 840 digital control with HLA module (number,
component, description)
No.in
Fig.
2-3
DescriptionComponent
L
1)
Handheld unit
S Connect HHU to K bus via MPI
S Handwheel, EMERGENCY STOP button, key-ac-
tuated switch, override, agreement buttons, dis-
play, unassigned keys
M
1)
Distribution box
S For linking the hand-held unit to the MPI bus
S Connection for EMERGENCY STOP circuit, en-
able keys, handwheel, 24 V DC
N Cable distributor
S 24V supply for connection to MPI connector
O Hydraulic Drive References:
/BR1/, “Servo solenoid valves” catalog
/BR2/, “Sensors and electronics” catalog
/BR3/, “Adapter plate valves” catalog
P External 24 V supply
S SITOP stabilized power supply modules
References: SITOP catalog
Order No. E860060-K2410-A101-A4
1) A description of these components can be found in:
References: /BH/, Operator Components Manual
Note
An HLA module must never be operated directly on a SIMODRIVE monitoring
module, i.e. it must always be connected via a mains infeed module.
For information about connecting further additional SIMODRIVE monitoring
modules in configurations with several HLA modules, please refer to the
Planning Guide for SIMODRIVE 611 Converters /PJU/.
In a multi-tier configuration, all the infeed supply units must be connected
simultaneously.
