Hardware and Connections
2-4 7SJ62 Manual
C53000-G1140-C121-1
View of Rear Panel Figure 2-2 is a simplified view of the rear panel of the version of the device with thread-
ed (screw-type) terminals and optical fiber ports for the service interface at location B.
Figure 2-2 Rear View of a 7SJ62 with Screw-type Terminals (example only)
