Appendix
A-197SJ62 Manual
C53000-G1140-C121-1
1305 50N-1 DELAY 0.00..60.00 sec 0.50 sec 50N-1 Time Delay
1307 51N PICKUP 0.50..20.00 A 1.00 A 51N Pickup
1308 51N TIME DIAL 0.05..3.20 sec 0.20 sec 51N Time Dial (IEC)
1309 51N TIME DIAL 0.50..15.00 5.00 51N Time Dial (ANSI)
1310 51N RESET Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1311 51N IEC CURVE Normal Inverse
Very Inverse
Extremely Inverse
Long Inverse
Normal Inverse IEC Curve
1312 51N ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inverse
Extremely Inverse
Definite Inverse
Very Inverse ANSI Curve
1313 MANUALCLOSEMODE 50N-2 instantaneously
50N-1 instantaneously
51N instantaneously
Inactive
50N-2 instantane-
ously
Manual Close Mode
1314 50N-2 active Always
with 79 Active
Always 50N-2 active
1330 50N/51N 50N/51N
1331 MofPU Res T/TEp Multiple of Pickup <-> T/TEp
1501 FCT 67/67-TOC OFF
ON
OFF 67, 67-TOC Phase Time Overcurrent
1502 67-2 PICKUP 0.50..175.00 A 10.00 A 67-2 Pickup
1503 67-2 DELAY 0.00..60.00 sec 0.10 sec 67-2 Time Delay
1504 67-1 PICKUP 0.50..175.00 A 5.00 A 67-1 Pickup
1505 67-1 DELAY 0.00..60.00 sec 0.50 sec 67-1Time Delay
1507 67-TOC PICKUP 0.50..20.00 A 5.00 A 67-TOC Pickup
1508 67 TIME DIAL 0.05..3.20 sec 0.50 sec 67-TOC Time Dial
1509 67 TIME DIAL 0.50..15.00 5.00 67-TOC Time Dial
1510 67-TOC Drop-out Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1511 67- IEC CURVE Normal Inverse
Very Inverse
Extremely Inverse
Long Inverse
Normal Inverse IEC Curve
1512 67- ANSI CURVE Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inverse
Extremely Inverse
Definite Inverse
Very Inverse ANSI Curve
Addr. Setting Title Setting Options Default Setting Comments
