Appendix
A-20 7SJ62 Manual
C53000-G1140-C121-1
1513 MANUALCLOSEMODE 67-2 instantaneously
67-1 instantaneously
67-TOC instantane-
ously
Inactive
67-2 instantane-
ously
Manual Close Mode
1514 67 active with 79 active
always
always 67 active
1515 Normal Load Inductive (135°)
Resistive (90°)
Capacitive(45°)
Inductive (135°) Normal Load (Torque angle of dir. fct)
1516 67 Direction Forward
Reverse
Forward Phase Direction
1530 67 67
1531 MofPU Res T/Tp Multiple of Pickup <-> T/Tp
1601 FCT 67N/67N-TOC OFF
ON
OFF 67N, 67N-TOC Ground Time Over-
current
1602 67N-2 PICKUP 0.25..175.00 A 2.50 A 67N-2 Pickup
1603 67N-2 DELAY 0.00..60.00 sec 0.10 sec 67N-2 Time Delay
1604 67N-1 PICKUP 0.25..175.00 A 1.00 A 67N-1 Pickup
1605 67N-1 DELAY 0.00..60.00 sec 0.50 sec 67N-1 Time Delay
1607 67N-TOC PICKUP 0.50..20.00 A 1.00 A 67N-TOC Pickup
1608 67N-TOC T-DIAL 0.05..3.20 sec 0.20 sec 67N-TOC Time Dial
1609 67N-TOC T-DIAL 0.50..15.00 5.00 67N-TOC Time Dial
1610 67N-TOC RESET Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1611 67N-TOC IEC Normal Inverse
Very Inverse
Extremely Inverse
Long Inverse
Normal Inverse IEC Curve
1612 67N-TOC ANSI Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inverse
Extremely Inverse
Definite Inverse
Very Inverse ANSI Curve
1613 MANUALCLOSEMODE 67N-2 instantaneously
67N-1 instantaneously
67N-TOC instantane-
ously
Inactive
67N-2 instantane-
ously
Manual Close Mode
1614 67N active always
with 79 active
always 67N active
1615 Normal Load Inductive (135°)
Resistive (90°)
Capacitive(45°)
Inductive (135°) Normal Load (Torque angle of dir. fct)
1616 67N Direction Forward
Reverse
Forward Ground Direction
Addr. Setting Title Setting Options Default Setting Comments
