Siemens SIPROTEC 7SJ62 Instruction Manual

Appendix
A-217SJ62 Manual
C53000-G1140-C121-1
1630 M.of PU TD Multiples of PU Time-Dial
1631 I/IEp Rf T/TEp 67N TOC
1701 COLDLOAD PICKUP OFF
ON
OFF Cold-Load-Pickup Function
1702 Start Condition No Current
Breaker Contact
No Current Start Condition
1703 CB Open Time 0..21600 sec 3600 sec Circuit Breaker OPEN Time
1704 Active Time 1..21600 sec 3600 sec Active Time
1705 Stop Time 1..600 sec 600 sec Stop Time
1801 50c-2 PICKUP 0.50..175.00 A 50.00 A 50c-2 Pickup
1802 50c-2 DELAY 0.00..60.00 sec 0.00 sec 50c-2 Time Delay
1803 50c-1 PICKUP 0.50..175.00 A 10.00 A 50c-1 Pickup
1804 50c-1 DELAY 0.00..60.00 sec 0.30 sec 50c-1 Time Delay
1805 51c PICKUP 0.50..20.00 A 7.50 A 51c Pickup
1806 51c TIME DIAL 0.05..3.20 sec 0.50 sec 51c Time dial (IEC)
1807 51c TIME DIAL 0.50..15.00 5.00 51c Time dial (ANSI)
1901 50Nc-2 PICKUP 0.25..175.00 A 35.00 A 50Nc-2 Pickup
1902 50Nc-2 DELAY 0.00..60.00 sec 0.00 sec 50Nc-2 Time Delay
1903 50Nc-1 PICKUP 0.25..175.00 A 7.50 A 50Nc-1 Pickup
1904 50Nc-1 DELAY 0.00..60.00 sec 0.30 sec 50Nc-1 Time Delay
1905 51Nc PICKUP 0.50..20.00 A 5.00 A 51Nc Pickup
1906 51Nc T-DIAL 0.05..3.20 sec 0.50 sec 51Nc Time Dial (IEC)
1907 51Nc T-DIAL 0.50..15.00 5.00 51Nc Time Dial (ANSI)
2001 67c-2 PICKUP 0.50..175.00 A 50.00 A 67c-2 Pickup
2002 67c-2 DELAY 0.00..60.00 sec 0.00 sec 67c-2 Time Delay
2003 67c-1 PICKUP 0.50.175.00 A 10.00 A 67c-1 Pickup
2004 67c-1 DELAY 0.00..60.00 sec 0.30 sec 67c-1 Time Delay
2005 67c-TOC PICKUP 0.50..20.00 A 7.50 A 67c Pickup
2006 67c-TOC T-DIAL 0.05..3.20 sec 0.50 sec 67c Time Dial
2007 67c-TOC T-DIAL 0.50..15.00 5.00 67c Time Dial
2101 50Nc-2 PICKUP 0.25..175.00 A 35.00 A 50Nc-2 Pickup
2102 67Nc-2 DELAY 0.00..60.00 sec 0.00 sec 67Nc-2 Time Delay
2103 67Nc-1 PICKUP 0.25..175.00 A 7.50 A 67Nc-1 Pickup
2104 67Nc-1 DELAY 0.00..60.00 sec 0.30 sec 67Nc-1 Time Delay
2105 67Nc-TOC PICKUP 0.50..20.00 A 5.00 A 67Nc-TOC Pickup
2106 67Nc-TOC T-DIAL 0.05..3.20 sec 0.50 sec 67Nc-TOC Time Dial
2107 67Nc-TOC T-DIAL 0.50..15.00 5.00 67Nc-TOC Time Dial
2201 INRUSH REST. OFF
ON
OFF Inrush Restraint
Addr. Setting Title Setting Options Default Setting Comments
