Appendix
A-237SJ62 Manual
C53000-G1140-C121-1
4001 FCT 46 OFF
ON
OFF 46 Negative Sequence Protection
4002 46-1 PICKUP 0.50..15.00 A 0.50 A 46-1 Pickup
4003 46-1 DELAY 0.00..60.00 sec 1.50 sec 46-1 Time Delay
4004 46-2 PICKUP 0.50..15.00 A 2.50 A 46-2 Pickup
4005 46-2 DELAY 0.00..60.00 sec 1.50 sec 46-2 Time Delay
4006 46 IEC CURVE Normal Inverse
Very Inverse
Extremely Inverse
Extremely Inverse IEC Curve
4007 46 ANSI CURVE Extremely Inverse
Inverse
Moderately Inverse
Very Inverse
Extremely Inverse ANSI Curve
4008 46-TOC PICKUP 0.50..10.00 A 4.50 A 46-TOC Pickup
4009 46-TOC TIMEDIAL 0.50..15.00 5.00 46-TOC Time Dial
4010 46-TOC TIMEDIAL 0.05..3.20 sec 0.50 sec 46-TOC Time Dial
4011 46-TOC RESET Instantaneous
Disk Emulation
Instantaneous 46-TOC Drop Out
4101 FCT 48/66 OFF
ON
OFF 48 / 66 Motor (Startup Monitor/Coun-
ter)
4102 STARTUP CURRENT 5.00..80.00 A 25.00 A Startup Current
4103 STARTUP TIME 1.0..180.0 sec 10.0 sec Startup Time
4104 LOCK ROTOR TIME 0.5..120.0 sec 2.0 sec Permissible Locked Rotor Time
4201 FCT 49 OFF
ON
Alarm Only
OFF 49 Thermal overload protection
4202 49 K-FACTOR 0.10..4.00 1.10 49 K-Factor
4203 TIME CONSTANT 1.0..999.9 min 100.0 min Time Constant
4204 49 Θ ALARM 50..100 % 90 % 49 Thermal Alarm Stage
4205 I ALARM 0.50..20.00 A 5.00 A Current Overload Alarm Setpoint
4207 Kτ-FACTOR 1.0..10.0 1.0 Kt-FACTOR when motor stops
4208 T EMERGENCY 10..15000 sec 100 sec Emergency time
4301 FCT 66 OFF
ON
OFF 66 Startup Counter for Motors
4302 IStart/IMOTnom 3.0..10.0 4.5 I Start / I Motor nominal
4303 T START MAX 3..120 sec 10 sec Maximum Permissible Starting Time
4304 T Equal 0.0..60.0 min 1.0 min Temperature Equalizaton Time
4305 I MOTOR NOMINAL 1.0..6.0 A 5.0 A Rated Motor Current
4306 MAX.WARM STARTS 1..4 2 Maximum Number of Warm Starts
4307 #COLD-#WARM 1..2 1 Number of Cold Starts - Warm Starts
4308 kτ-FACTOR 1..10 2 Kt-Factor at Stop
Addr. Setting Title Setting Options Default Setting Comments
