Siemens SIPROTEC 7SJ62 Instruction Manual

Appendix
A-24 7SJ62 Manual
C53000-G1140-C121-1
5001 FCT 59 OFF
ON
Alarm Only
OFF 59 Overvoltage Protection
5002 59-1 PICKUP 40..225 V 110 V 59-1 Pickup
5003 59-1 PICKUP 40..130 V 110 V 59-1 Pickup
5004 59-1 DELAY 0.00..60.00 sec 0.50 sec 59-1 Time Delay
5101 FCT 27 OFF
ON
Alarm Only
OFF 27 Undervoltage Protection
5102 27-1 PICKUP 30..210 V 75 V 27-1 Pickup
5103 27-1 PICKUP 30..120 V 75 V 27-1 Pickup
5105 27-1 DOUT RATIO 1.05..3.00 1.20 27-1 Drop out Ratio
5106 27-1 DELAY 0.00..60.00 sec 1.50 sec 27-1 Time Delay
5110 27-2 PICKUP 30..210 V 70 V 27-2 Pickup
5111 27-2 PICKUP 30..120 V 70 V 27-2 Pickup
5112 27-2 DELAY 0.00..60.00 sec 0.50 sec 27-2 Time Delay
5120 CURRENT SUPERV. OFF
ON
ON Current Supervision
5301 FUSE FAIL MON. ON
OFF
OFF Fuse Fail Monitor
5302 FUSE FAIL 3Vo 10..100 V 30 V Zero Sequence Voltage
5303 FUSE FAIL RESID 0.50..5.00 A 0.50 A Residual Current
5401 FCT 81 O/U OFF
ON
OFF 81 Over/Under Frequency Protection
5402 Vmin 40..120 V 65 V Minimum required voltage for opera-
tion
5403 81-1 PICKUP 45.50..54.50 Hz 49.50 Hz 81-1 Pickup
5404 81-1 PICKUP 55.50..64.50 Hz 59.50 Hz 81-1 Pickup
5405 81-1 DELAY 0.00..100.00 sec 60.00 sec 81-1 Time Delay
5406 81-2 PICKUP 45.50..54.50 Hz 49.00 Hz 81-2 Pickup
5407 81-2 PICKUP 55.50..64.50 Hz 59.00 Hz 81-2 Pickup
5408 81-2 DELAY 0.00..100.00 sec 30.00 sec 81-2 Time Delay
5409 81-3 PICKUP 45.50..54.50 Hz 47.50 Hz 81-3 Pickup
5410 81-3 PICKUP 55.50..64.50 Hz 57.50 Hz 81-3 Pickup
5411 81-3 DELAY 0.00..100.00 sec 3.00 sec 81-3 Time delay
5412 81-4 PICKUP 45.50..54.50 Hz 51.00 Hz 81-4 Pickup
5413 81-4 PICKUP 55.50..64.50 Hz 61.00 Hz 81-4 Pickup
5414 81-4 DELAY 0.00..100.00 sec 30.00 sec 81-4 Time delay
7001 FCT 50BF OFF
ON
OFF 50BF Breaker Failure Protection
7004 Chk BRK CONTACT OFF
ON
OFF Check Breaker contacts
Addr. Setting Title Setting Options Default Setting Comments
