Appendix
A-257SJ62 Manual
C53000-G1140-C121-1
7005 TRIP-Timer 0.06..60.00 sec 0.25 sec TRIP-Timer
7101 FCT 79 OFF
ON
OFF 79 Auto-Reclose Function
7103 BLK MAN. CLOSE NO
YES
NO Block Manual close
7105 TIME RESTRAINT 0.50..320.00 sec 3.00 sec 79 Auto Reclosing reset time
7108 SAFETY 79 ready 0.01..300.00 sec 15.00 sec Safety Time until 79 is ready
7110 FltDisp.LED/LCD Display Targets on
every Pickup
Display Targets on
TRIP only
Display Targets on
every Pickup
Fault Display on LED / LCD
7113 CHECK CB? No check
Check each cycle
No check Check circuit breaker before AR?
7115 CB TIME OUT 0.10..320.00 sec 3.00 sec Circuit Breaker (CB) Supervision
Time
7116 MAX.InhibitTIME 0.01..320.00 sec 15.00 sec Maximum Inhibit Time allowed for
ext. BI
7127 DEADTIME 1: PH 0.01..320.00 sec 0.50 sec Dead Time 1: Phase Fault
7128 DEADTIME 1: G 0.01..320.00 sec 0.50 sec Dead Time 1: Ground Fault
7129 DEADTIME 2: PH 0.01..320.00 sec 0.50 sec Dead Time 2: Phase Fault
7130 DEADTIME 2: G 0.01..320.00 sec 0.50 sec Dead Time 2: Ground Fault
7131 DEADTIME 3: PH 0.01..320.00 sec 0.50 sec Dead Time 3: Phase Fault
7132 DEADTIME 3: G 0.01..320.00 sec 0.50 sec Dead Time 3: Ground Fault
7133 DEADTIME 4: PH 0.01..320.00 sec 0.50 sec Dead Time 4: Phase Fault
7134 DEADTIME 4: G 0.01..320.00 sec 0.50 sec Dead Time 4: Ground Fault
7135 # OF RECL. GND 0..9 1 Number of Reclosing Cycles Ground
7136 # OF RECL. PH 0..9 1 Number of Reclosing Cycles Phase
7140 ZONE SEQ.COORD. OFF
ON
OFF ZSC - Zone sequence coordination
7150 50-1/50N-1 No influence
Starts 79
Stops 79
No influence 50-1, 50N-1
7151 50-2/50N-2 No influence
Starts 79
Stops 79
No influence 50-2, 50N-2
7152 51/51N No influence
Starts 79
Stops 79
No influence 51, 51N
7153 67-1/67N-1 No influence
Starts 79
Stops 79
No influence 67-1, 67N-1
7154 67-2/67N-2 No influence
Starts 79
Stops 79
No influence 67-2, 67N-2
