Siemens SIPROTEC 7SJ62 Instruction Manual

Appendix
A-26 7SJ62 Manual
C53000-G1140-C121-1
7155 67-TOC/67N-TOC No influence
Starts 79
Stops 79
No influence 67-TOC, 67N-TOC
7156 sens Ground Flt No influence
Starts 79
Stops 79
No influence Sensitive Ground Fault
7157 46 No influence
Starts 79
Stops 79
No influence 46
7158 BINARY INPUT No influence
Starts 79
Stops 79
No influence Binary Input
7159 3Pol.PICKUP BLK YES
NO
NO 3 Pole Pickup blocks 79
7170 1.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 50-1, 50N-1
7171 1.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 50-2, 50N-2
7172 1.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 67-1, 67N-1
7173 1.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 67-2, 67N-2
7174 2.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 50-1, 50N-1
7175 2.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 50-2, 50N-2
7176 2.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 67-1, 67N-1
7177 2.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 67-2, 67N-2
7178 3.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 50-1, 50N-1
7179 3.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 50-2, 50N-2
7180 3.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 67-1, 67N-1
7181 3.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 67-2, 67N-2
Addr. Setting Title Setting Options Default Setting Comments
