Siemens SIPROTEC 7SJ62 Instruction Manual

Appendix
A-277SJ62 Manual
C53000-G1140-C121-1
7182 4.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 50-1, 50N-1
7183 4.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 50-2, 50N-2
7184 4.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 67-1, 67N-1
7185 4.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 67-2, 67N-2
8001 START Pickup
TRIP
Pickup Start fault locator with
8101 MEASURE. SUPERV OFF
ON
ON Measurement Supervision
8102 BALANCE V-LIMIT 10..100 V 50 V Voltage Threshold for Balance Moni-
toring
8103 BAL. FACTOR V 0.58..0.90 0.75 Balance Factor for Voltage Monitor
8104 BALANCE I LIMIT 0.50..5.00 A 2.50 A Current Threshold for Balance Moni-
toring
8105 BAL. FACTOR I 0.10..0.90 0.50 Balance Factor for Current Monitor
8106 Σ I THRESHOLD 0.25..10.00 A 0.50 A Summated Current Monitoring Thres-
hold
8107 Σ I FACTOR 0.00..0.95 0.10 Summated Current Monitoring Factor
8201 FCT 74TC ON
OFF
ON 74TC TRIP Circuit Supervision
8311 MinMax cycRESET NO
YES
YES Automatic Cyclic Reset Function
8312 MiMa RESET TIME 0..1439 min 0 min MinMax Reset Timer
8313 MiMa RESETCYCLE 1..365 day(s) 7 day(s) MinMax Reset Cycle Period
8314 MinMaxRES.START 1..365 Days 1 Days MinMax Start Reset Cycle in
Addr. Setting Title Setting Options Default Setting Comments
