Appendix
A-34 7SJ62 Manual
C53000-G1140-C121-1
924 Wp Forward MVMV 133 51 205
925 Wq Forward MVMV 133 52 205
928 Wp Reverse MVMV 133 53 205
929 Wq Reverse MVMV 133 54 205
888 Pulsed Energy Wp (active) PMV 133 55 205
889 Pulsed Energy Wq (reactive) PMV 133 56 205
533 Primary fault current Ia (Ia =) OUT O/O O/O GI 150 177 4
534 Primary fault current Ib (Ib =) OUT O/O O/O GI 150 178 4
535 Primary fault current Ic (Ic =) OUT O/O O/O GI 150 179 4
501 Relay PICKUP (Relay PICKUP) OUT O M LED REL O/O GI 150 151 2 GI
511 Relay GENERAL TRIP command
(Relay TRIP)
OUT O M LED REL O/O GI 150 161 2 GI
561 Manual close signal detected
(Man.Clos.Detect)
OUT O/O LED REL O/O GI
4601 >52-a contact (OPEN, if bkr is open)
(>52-a)
SP LED BI REL O/O GI
4602 >52-b contact (OPEN, if bkr is closed)
(>52-b)
SP LED BI REL O/O GI
126 Protection ON/OFF (via system port)
(ProtON/OFF)
IntSP O/O LED REL O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
