A-357SJ62 Manual
C53000-G1140-C121-1
1761 50(N)/51(N) O/C PICKUP (50(N)/51(N)
PU)
OUT O/O M LED REL OO/
G
GI 160 84 2 GI
1791 50(N)/51(N) TRIP (50(N)/51(N)TRIP) OUT O M LED REL O/O GI 160 68 2
1704 >BLOCK 50/51 (>BLK 50/51) SP LED BI REL O/O GI
1721 >BLOCK 50-2 (>BLOCK 50-2) SP LED BI REL O/O GI 60 1 1 GI
1722 >BLOCK 50-1 (>BLOCK 50-1) SP LED BI REL O/O GI 60 2 1 GI
1723 >BLOCK 51 (>BLOCK 51) SP LED BI REL O/O GI 60 3 1 GI
1751 50/51 O/C switched OFF (50/51 PH
OFF)
OUT O/O LED REL O/O GI 60 21 1 GI
1752 50/51 O/C is BLOCKED (50/51 PH
BLK)
OUT O/O O/O LED REL OO/
G
GI 60 22 1 GI
1753 50/51 O/C is ACTIVE (50/51 PH ACT) OUT O/O LED REL O/O GI 60 23 1 GI
1762 50/51 Phase A picked up (50/51 Ph A
PU)
OUT O/O M LED REL O/O GI 160 64 2 GI
1763 50/51 Phase B picked up (50/51 Ph B
PU)
OUT O/O M LED REL O/O GI 160 65 2 GI
1764 50/51 Phase C picked up (50/51 Ph C
PU)
OUT O/O M LED REL O/O GI 160 66 2 GI
1800 50-2 picked up (50-2 picked up) OUT O/O LED REL O/O GI 60 75 2 GI
1805 50-2 TRIP (50-2 TRIP) OUT O M LED REL O/O GI 160 91 2
1810 50-1 picked up (50-1 picked up) OUT O/O LED REL O/O GI 60 76 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
