Appendix
A-36 7SJ62 Manual
C53000-G1140-C121-1
1815 50-1 TRIP (50-1 TRIP) OUT O M LED REL O/O GI 160 90 2
1820 51 picked up (51 picked up) OUT O/O LED REL O/O GI 60 77 2 GI
1825 51 TRIP (51 TRIP) OUT O M LED REL O/O GI 60 58 2 GI
1866 51 Disk emulation Pickup (51Disk PU) OUT O/O GI
1804 50-2 Time Out (50-2 TimeOut) OUT LED REL O/O GI 60 49 2 GI
1814 50-1 Time Out (50-1 TimeOut) OUT LED REL O/O GI 60 53 2 GI
1824 51 Time Out (51 Time Out) OUT LED REL O/O GI 60 57 2 GI
1852 50-2 BLOCKED (50-2 BLOCKED) OUT O/O O/O LED REL O/O GI 60 106 1 GI
1851 50-1 BLOCKED (50-1 BLOCKED) OUT O/O O/O LED REL O/O GI 60 105 1 GI
1855 51 BLOCKED (51 BLOCKED) OUT O/O O/O LED REL O/O GI 60 109 1 GI
1714 >BLOCK 50N/51N (>BLK 50N/51N) SP LED BI REL O/O GI
1724 >BLOCK 50N-2 (>BLOCK 50N-2) SP LED BI REL O/O GI 60 4 1 GI
1725 >BLOCK 50N-1 (>BLOCK 50N-1) SP LED BI REL O/O GI 60 5 1 GI
1726 >BLOCK 51N (>BLOCK 51N) SP LED BI REL O/O GI 60 6 1 GI
1756 50N/51N is OFF (50N/51N OFF) OUT O/O LED REL O/O GI 60 26 1 GI
1757 50N/51N is BLOCKED (50N/51N BLK) OUT O/O O/O LED REL O/O GI 60 27 1 GI
1758 50N/51N is ACTIVE (50N/51N ACT) OUT O/O LED REL O/O GI 60 28 1 GI
1765 50N/51N picked up (50N/51NPickedup) OUT O/O M LED REL O/O GI 160 67 2 GI
1831 50N-2 picked up (50N-2 picked up) OUT O/O LED REL O/O GI 60 59 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
