Appendix
A-377SJ62 Manual
C53000-G1140-C121-1
1833 50N-2 TRIP (50N-2 TRIP) OUT O M LED REL O/O GI 160 93 2
1834 50N-1 picked up (50N-1 picked up) OUT O/O LED REL O/O GI 60 62 2 GI
1836 50N-1 TRIP (50N-1 TRIP) OUT O M LED REL O/O GI 160 92 2
1837 51N picked up (51N picked up) OUT O/O LED REL O/O GI 60 64 2 GI
1839 51N TRIP (51N TRIP) OUT O M LED REL O/O GI 60 66 2 GI
1867 51N Disk emulation picked up (51N Disk
Pickup)
OUT O/O GI
1832 50N-2 Time Out (50N-2 TimeOut) OUT LED REL O/O GI 60 60 2 GI
1835 50N-1 Time Out (50N-1 TimeOut) OUT LED REL O/O GI 60 63 2 GI
1838 51N Time Out (51N TimeOut) OUT LED REL O/O GI 60 65 2 GI
1854 50N-2 BLOCKED (50N-2 BLOCKED) OUT O/O O/O LED REL O/O GI 60 108 1 GI
1853 50N-1 BLOCKED (50N-1 BLOCKED) OUT O/O O/O LED REL O/O GI 60 107 1 GI
1856 51N BLOCKED (51N BLOCKED) OUT O/O O/O LED REL O/O GI 60 110 1 GI
7563 >BLOCK InRush Phase (>BLOCK
InRushPh)
SP LED BI REL O/O GI
1840 Phase A trip blocked by inrush detection
(PhA InrushBlk)
OUT O/O LED REL O/O GI 60 101 2 GI
1841 Phase B trip blocked by inrush detection
(PhB InrushBlk)
OUT O/O LED REL O/O GI 60 102 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
