Appendix
A-38 7SJ62 Manual
C53000-G1140-C121-1
1842 Phase C trip blocked by inrush detection
(PhC InrushBlk)
OUT O/O LED REL O/O GI 60 103 2 GI
1843 Cross blk: PhX blocked PhY (INRUSH
X-BLK)
OUT O/O LED REL O/O GI 60 104 2 GI
7551 50-1 InRush picked up (50-1 InRushPU) OUT O/O LED REL O/O GI 60 80 2 GI
7552 50N-1 InRush picked up (50N-1 InRus-
hPU)
OUT O/O LED REL O/O GI 60 81 2 GI
7553 51 InRush picked up (51 InRushPU) OUT O/O LED REL O/O GI 60 82 2 GI
7554 51N InRush picked up (51N InRushPU) OUT O/O LED REL O/O GI 60 83 2 GI
7556 InRush OFF (InRush OFF) OUT O/O LED REL O/O GI 60 92 1 GI
7557 InRush Phase BLOCKED (InRushPh-
BLOCKED)
OUT O/O O/O LED REL O/O GI 60 93 1 GI
7558 InRush Ground BLOCKED (InRush Gnd
BLK)
OUT O/O LED REL O/O GI 60 94 1 GI
7559 67-1 InRush picked up (67-1 InRushPU) OUT O/O LED REL O/O GI 60 84 2 GI
7560 67N-1 InRush picked up (67N-1 InRus-
hPU)
OUT O/O LED REL O/O GI 60 85 2 GI
7561 67-TOC InRush picked up (67-TOC
InRushPU)
OUT O/O LED REL O/O GI 60 86 2 GI
7562 67N-TOC InRush picked up (67N-
TOCInRushPU)
OUT O/O LED REL O/O GI 60 87 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
