Appendix
A-397SJ62 Manual
C53000-G1140-C121-1
7565 Phase A InRush picked up (Ia InRush
PU)
OUT O/O LED REL O/O GI 60 89 2 GI
7566 Phase B InRush picked up (Ib InRush
PU)
OUT O/O LED REL O/O GI 60 90 2 GI
7567 Phase C InRush picked up (Ic InRush
PU)
OUT O/O LED REL O/O GI 60 91 2 GI
7564 Ground InRush picked up (Gnd InRush
PU)
OUT O/O LED REL O/O GI 60 88 2 GI
2691 67/67N picked up (67/67N pickedup) OUT O/O M LED REL O/O GI 63 50 2 GI
2696 67/67N TRIP (67/67N TRIP) OUT O M LED REL O/O GI 63 55 2 GI
2604 >BLOCK 67/67-TOC (>BLK 67/67-TOC) SP LED BI REL O/O GI
2615 >BLOCK 67-2 (>BLOCK 67-2) SP LED BI REL O/O GI 63 73 1 GI
2621 >BLOCK 67-1 (>BLOCK 67-1) SP LED BI REL O/O GI 63 1 1 GI
2622 >BLOCK 67-TOC (>BLOCK 67-TOC) SP LED BI REL O/O GI 63 2 1 GI
2651 67/67-TOC switched OFF (67/67-TOC
OFF)
OUT O/O LED REL O/O GI 63 10 1 GI
2652 67/67-TOC is BLOCKED (67 BLOK-
KED)
OUT O/O O/O LED REL O/O GI 63 11 1 GI
2653 67/67-TOC is ACTIVE (67 ACTIVE) OUT O/O LED REL O/O GI 63 12 1 GI
2642 67-2 picked up (67-2 picked up) OUT O/O LED REL O/O GI 63 67 2 GI
2649 67-2 TRIP (67-2 TRIP) OUT O M LED REL O/O GI 63 72 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
