Appendix
A-40 7SJ62 Manual
C53000-G1140-C121-1
2660 67-1 picked up (67-1 picked up) OUT O/O LED REL O/O GI 63 20 2 GI
2665 67-1 TRIP (67-1 TRIP) OUT O M LED REL O/O GI 63 25 2 GI
2670 67-TOC picked up (67-TOC pickedup) OUT O/O LED REL O/O GI 63 30 2 GI
2675 67-TOC TRIP (67-TOC TRIP) OUT O M LED REL O/O GI 63 35 2 GI
2692 67/67-TOC Phase A picked up (67 A
picked up)
OUT O/O LED REL O/O GI 63 51 2 GI
2693 67/67-TOC Phase B picked up (67 B
picked up)
OUT O/O LED REL O/O GI 63 52 2 GI
2694 67/67-TOC Phase C picked up (67 C
picked up)
OUT O/O LED REL O/O GI 63 53 2 GI
2647 67-2 Time Out (67-2 Time Out) OUT LED REL O/O GI 63 71 2 GI
2664 67-1 Time Out (67-1 Time Out) OUT LED REL O/O GI 63 24 2 GI
2674 67-TOC Time Out (67-TOC Time Out) OUT LED REL O/O GI 63 34 2 GI
2628 Phase A forward (Phase A forward) OUT O LED REL O/O GI 63 81 1 GI
2629 Phase B forward (Phase B forward) OUT O LED REL O/O GI 63 82 1 GI
2630 Phase C forward (Phase C forward) OUT O LED REL O/O GI 63 83 1 GI
2632 Phase A reverse (Phase A reverse) OUT O LED REL O/O GI 63 84 1 GI
2633 Phase B reverse (Phase B reverse) OUT O LED REL O/O GI 63 85 1 GI
2634 Phase C reverse (Phase C reverse) OUT O LED REL O/O GI 63 86 1 GI
2637 67-1 is BLOCKED (67-1 BLOCKED) OUT O/O O/O LED REL O/O GI 63 91 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
