Appendix
A-417SJ62 Manual
C53000-G1140-C121-1
2655 67-2 is BLOCKED (67-2 BLOCKED) OUT O/O O/O LED REL O/O GI 63 92 1 GI
2669 67-TOC is BLOCKED (67-TOC BLOK-
KED)
OUT O/O O/O LED REL O/O GI 63 95 1 GI
2676 67-TOC disk emulation is ACTIVE (67-
TOC DiskPU)
OUT O/O GI
2614 >BLOCK 67N/67N-TOC (>BLK 67N/
67NTOC)
SP LED BI REL O/O GI
2616 >BLOCK 67N-2 (>BLOCK 67N-2) SP LED BI REL O/O GI 63 74 1 GI
2623 >BLOCK 67N-1 (>BLOCK 67N-1) SP LED BI REL O/O GI 63 3 1 GI
2624 >BLOCK 67N-TOC (>BLOCK 67N-
TOC)
SP LED BI REL O/O GI 63 4 1 GI
2656 67N/67N-TOC switched OFF (67N
OFF)
OUT O/O LED REL O/O GI 63 13 1 GI
2657 67N/67N-TOC is BLOCKED (67N
BLOCKED)
OUT O/O O/O LED REL O/O GI 63 14 1 GI
2658 67N/67N-TOC is ACTIVE (67N
ACTIVE)
OUT O/O LED REL O/O GI 63 15 1 GI
2646 67N-2 picked up (67N-2 picked up) OUT O/O LED REL O/O GI 63 62 2 GI
2679 67-2 TRIP (67N-2 TRIP) OUT O M LED REL O/O GI 63 64 2 GI
2681 67N-1 picked up (67N-1 picked up) OUT O/O LED REL O/O GI 63 41 2 GI
2683 67N-1 TRIP (67N-1 TRIP) OUT O M LED REL O/O GI 63 43 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
