Appendix
A-457SJ62 Manual
C53000-G1140-C121-1
5151 46 switched OFF (46 OFF) OUT O/O LED REL O/O GI 70 131 1 GI
5152 46 is BLOCKED (46 BLOCKED) OUT O/O O/O LED REL O/O GI 70 132 1 GI
5153 46 is ACTIVE (46 ACTIVE) OUT O/O LED REL O/O GI 70 133 1 GI
5159 46-2 picked up (46-2 picked up) OUT O/O LED REL O/O GI 70 138 2 GI
5165 46-1 picked up (46-1 picked up) OUT O/O LED REL O/O GI 70 150 2 GI
5166 46-TOC picked up (46-TOC pickedup) OUT O/O LED REL O/O GI 70 141 2 GI
5170 46 TRIP (46 TRIP) OUT O M LED REL O/O GI 70 149 2 GI
5171 46 Disk emulation picked up (46 Dsk
pickedup)
OUT LED REL O/O GI
6801 >BLOCK Startup Supervision (>BLK
START-SUP)
SP LED BI REL O/O GI
6805 >Rotor locked (>Rotor locked) SP LED BI REL O/O GI
6811 Startup supervision OFF (START-SUP
OFF)
OUT O/O LED REL O/O GI 169 51 1 GI
6812 Startup supervision is BLOCKED
(START-SUP BLK)
OUT O/O O/O LED REL O/O GI 169 52 1 GI
6813 Startup supervision is ACTIVE (START-
SUP ACT)
OUT O/O LED REL O/O GI 169 53 1 GI
6821 Startup supervision TRIP (START-SUP
TRIP)
OUT O M LED REL O/O GI 169 54 2 GI
6822 Rotor locked (Rotor locked) OUT O LED REL O/O GI 169 55 2 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
