Appendix
A-46 7SJ62 Manual
C53000-G1140-C121-1
6823 Startup supervision Pickup (START-
SUP pu)
OUT O/O LED REL O/O GI 169 56 1 GI
4822 >BLOCK Motor Startup counter
(>BLOCK 66)
SP LED BI REL O/O GI
4823 >Emergency start (>66 emer.start) SP O/O LED BI REL O/O GI 168 51 1 GI
4824 66 Motor start protection OFF (66 OFF) OUT O/O LED REL O/O GI 168 52 1 GI
4825 66 Motor start protection BLOCKED (66
BLOCKED)
OUT O/O O/O LED REL O/O GI 168 53 1 GI
4826 66 Motor start protection ACTIVE (66
ACTIVE)
OUT O/O LED REL O/O GI 168 54 1 GI
4827 66 Motor start protection TRIP (66 TRIP) OUT O/O LED REL O/O GI 168 55 1 GI
5203 >BLOCK 81O/U (>BLOCK 81O/U) SP O/O LED BI REL O/O GI 70 176 1 GI
5206 >BLOCK 81-1 (>BLOCK 81-1) SP O/O LED BI REL O/O GI 70 177 1 GI
5207 >BLOCK 81-2 (>BLOCK 81-2) SP O/O LED BI REL O/O GI 70 178 1 GI
5208 >BLOCK 81-3 (>BLOCK 81-3) SP O/O LED BI REL O/O GI 70 179 1 GI
5209 >BLOCK 81-4 (>BLOCK 81-4) SP O/O LED BI REL O/O GI 70 180 1 GI
5211 81 OFF (81 OFF) OUT O/O LED REL O/O GI 70 181 1 GI
5212 81 BLOCKED (81 BLOCKED) OUT O/O O/O LED REL O/O GI 70 182 1 GI
5213 81 ACTIVE (81 ACTIVE) OUT O/O LED REL O/O GI 70 183 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
