Appendix
A-477SJ62 Manual
C53000-G1140-C121-1
5214 81 Under Voltage Block (81 Under V
Blk)
OUT O/O O/O LED REL O/O GI 70 184 1 GI
5232 81-1 picked up (81-1 picked up) OUT O/O LED REL O/O GI 70 230 2 GI
5233 81-2 picked up (81-2 picked up) OUT O/O LED REL O/O GI 70 231 2 GI
5234 81-3 picked up (81-3 picked up) OUT O/O LED REL O/O GI 70 232 2 GI
5235 81-4 picked up (81-4 picked up) OUT O/O LED REL O/O GI 70 233 2 GI
5236 81-1 TRIP (81-1 TRIP) OUT O M LED REL O/O GI 70 234 2 GI
5237 81-2 TRIP (81-2 TRIP) OUT O M LED REL O/O GI 70 235 2 GI
5238 81-3 TRIP (81-3 TRIP) OUT O M LED REL O/O GI 70 236 2 GI
5239 81-4 TRIP (81-4 TRIP) OUT O M LED REL O/O GI 70 237 2 GI
1503 >BLOCK 49 Overload Protection
(>BLOCK 49 O/L)
SP LED BI REL O/O GI 167 3 1 GI
1507 >Emergency start of motors (>Emergen-
cyStart)
SP O/O LED BI REL O/O GI 167 7 1 GI
1511 49 Overload Protection is OFF (49 O / L
OFF)
OUT O/O LED REL O/O GI 167 11 1 GI
1512 49 Overload Protection is BLOCKED
(49 O/L BLOCK)
OUT O/O O/O LED REL O/O GI 167 12 1 GI
1513 49 Overload Protection is ACTIVE (49
O/L ACTIVE)
OUT O/O LED REL O/O GI 167 13 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
