Appendix
A-48 7SJ62 Manual
C53000-G1140-C121-1
1515 49 Overload Current Alarm (I alarm) (49
O/L I Alarm)
OUT O/O LED REL O/O GI 167 15 1 GI
1516 49 Overload Alarm! Near Thermal Trip
(49 O/L Θ Alarm)
OUT O/O LED REL O/O GI 167 16 1 GI
1517 49 Winding Overload (49 Winding O/L) OUT O/O LED REL O/O GI 167 17 1 GI
1521 49 Thermal Overload TRIP (49 Th O/L
TRIP)
OUT O M LED REL O/O GI 167 21 2 GI
162 Failure: Current Summation (Failure Σ I) OUT O/O LED REL O/O GI 135 182 1 GI
163 Failure: Current Balance (Fail I balance) OUT O/O LED REL O/O GI 135 183 1 GI
167 Failure: Voltage Balance (Fail V
balance)
OUT O/O LED REL O/O GI 135 186 1 GI
161 Failure: general Current Supervision
(Fail I Superv.)
OUT O/O LED REL O/O GI 160 32 1 GI
171 Failure: Phase Sequence (Fail Ph. Seq.) OUT O/O LED REL O/O GI 160 35 1 GI
176 Failure: Phase Sequence Voltage (Fail
Ph. Seq. V)
OUT O/O LED REL O/O GI 135 192 1 GI
175 Failure: Phase Sequence Current (Fail
Ph. Seq. I)
OUT O/O LED REL O/O GI 135 191 1 GI
197 Measurement Supervision is switched
OFF (MeasSup OFF)
OUT O/O LED REL O/O GI 135 197 1 GI
6509 >Failure: Feeder VT (>FAIL:FEEDER
VT)
SP O/O LED BI REL O/O GI 74 9 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
