Appendix
A-50 7SJ62 Manual
C53000-G1140-C121-1
1207 >BLOCK 50Ns/67Ns (>BLK 50Ns/67Ns) SP O/O LED BI REL O/O GI 151 107 1 GI
1211 50Ns/67Ns is OFF (50Ns/67Ns OFF) OUT O/O LED REL O/O GI 151 111 1 GI
1212 50Ns/67Ns is ACTIVE (50Ns/67Ns
ACT)
OUT O/O LED REL O/O GI 151 112 1 GI
1215 64 displacement voltage pick up (64 PU) OUT O/O LED REL O/O GI 151 115 2 GI
1217 64 displacement voltage element TRIP
(64 TRIP)
OUT O M LED REL O/O GI 151 117 2 GI
1221 50Ns-2 Pickup (50Ns-2 Pickup) OUT O/O LED REL O/O GI 151 121 2 GI
1223 50Ns-2 TRIP (50Ns-2 TRIP) OUT O M LED REL O/O GI 151 123 2 GI
1224 50Ns-1 Pickup (50Ns-1 Pickup) OUT O/O LED REL O/O GI 151 124 2 GI
1226 50Ns-1 TRIP (50Ns-1 TRIP) OUT O M LED REL O/O GI 151 126 2 GI
1227 51Ns picked up (51Ns Pickup) OUT O/O LED REL O/O GI 151 127 2 GI
1229 51Ns TRIP (51Ns TRIP) OUT O M LED REL O/O GI 151 129 2 GI
1230 Sensitive ground fault detection BLOK-
KED (Sens. Gnd block)
OUT O/O O/O LED REL O/O GI 151 130 1 GI
1272 Sensitive Ground fault picked up in Ph A
(Sens. Gnd Ph A)
OUT O/O O O LED REL O/O GI 160 48 1 GI
1273 Sensitive Ground fault picked up in Ph B
(Sens. Gnd Ph B)
OUT O/O O O LED REL O/O GI 160 49 1 GI
1274 Sensitive Ground fault picked up in Ph O
(Sens. Gnd Ph C)
OUT O/O O O LED REL O/O GI 160 50 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
