Appendix
A-517SJ62 Manual
C53000-G1140-C121-1
1276 Sensitive Gnd fault in forward direction
(SensGnd Forward)
OUT O/O O O LED REL O/O GI 160 51 1 GI
1277 Sensitive Gnd fault in reverse direction
(SensGnd Reverse)
OUT O/O O O LED REL O/O GI 160 52 1 GI
1278 Sensitive Gnd fault direction undefined
(SensGnd undef.)
OUT O/O O O LED REL O/O GI 151 178 1 GI
2701 >79 ON (>79 ON) SP LED BI REL O/O GI 40 1 1 GI
2702 >79 OFF (>79 OFF) SP LED BI REL O/O GI 40 2 1 GI
2703 >BLOCK 79 (>BLOCK 79) SP O/O LED BI REL O/O GI 40 3 1 GI
2705 >79 T Wait (coordination control) (>79 T
WAIT)
SP O/O LED BI REL O/O GI 40 10 1 GI
2730 >Circuit breaker READY for reclosing
(>CB Ready)
SP O/O LED BI REL O/O GI 40 30 1 GI
2715 >79 Ext. 1pole TRIP for internal A/R
(>79 TRIP 1p)
SP LED BI REL O/O GI 40 15 1 GI
2716 >79 Ext. 3pole TRIP for internal A/R
(>79 TRIP 3p)
SP LED BI REL O/O GI 40 16 1 GI
2722 >Switch zone sequence coordination
ON (>ZSC ON)
SP LED BI REL O/O GI
2723 >Switch zone sequence coordination
OFF (>ZSC OFF)
SP LED BI REL O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
