Appendix
A-52 7SJ62 Manual
C53000-G1140-C121-1
2781 79 Auto recloser is switched OFF (79
OFF)
OUT O/O LED REL O/O GI 40 81 1 GI
2782 79 Auto recloser is switched ON (79
ON)
IntSP LED REL O/O GI 160 16 1 GI
2784 Circuit breaker is NOT ready (CB is NOT
ready)
OUT O/O O/O LED REL O/O GI 160 130 1 GI
2785 79 - Auto-reclose is dynamically BLOK-
KED (79 DynBlock)
OUT O/O O/O LED REL O/O GI 40 85 1 GI
2801 79 - in progress (79 in progress) OUT O LED REL O/O GI 40 101 1 GI
2851 79 - Close command (79 Close) OUT O M LED REL O/O GI 160 128 1
2862 79 - cycle successful (79 Successful) OUT O LED REL O/O GI 40 162 1 GI
2863 79 - Lockout (79 Lockout) OUT LED REL O/O GI 40 163 2 GI
2869 TRIP Ground Fault (TRIP Gnd Fault) OUT O/O LED REL O/O GI
2870 TRIP Phase Fault (TRIP Ph Fault) OUT O/O LED REL O/O GI
2876 79-A/R attempt step (79 STEP) OUT O/O O/O GI 40 182 2 GI
2878 79-A/R single phase reclosing sequence
(79 L-N Sequence)
OUT O LED REL O/O GI 40 180 2 GI
2879 79-A/R multi-phase reclosing sequence
(79 L-L Sequence)
OUT O LED REL O/O GI 40 181 2 GI
2883 Zone Sequencing is active (ZSC active) OUT O LED REL O/O GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
