Appendix
A-537SJ62 Manual
C53000-G1140-C121-1
2884 Zone sequence coordination switched
ON (ZSC ON)
OUT LED REL O/O GI
2885 Zone sequence coordination switched
OFF (ZSC OFF)
OUT O/O LED REL O/O GI
127 79 ON/OFF (via system port) (79 ON/
OFF)
IntSP O/O LED REL O/O GI
1106 >Start Fault Locator (>Start Flt. Loc) SP O LED BI REL O/O GI 151 6 1 GI
1118 Flt Locator: secondary REACTANCE
(Xsec =)
OUT O/O O/O GI 151 18 4
1119 Flt Locator: Distance to fault (dist =) OUT O/O O/O GI 151 19 4
1123 Fault Locator Loop AG (FL Loop AG) OUT O O/O GI
1124 Fault Locator Loop BG (FL Loop BG) OUT O O/O GI
1125 Fault Locator Loop CG (FL Loop CG) OUT O O/O GI
1126 Fault Locator Loop AB (FL Loop AB) OUT O O/O GI
1127 Fault Locator Loop BC (FL Loop BC) OUT O O/O GI
1128 Fault Locator Loop CA (FL Loop CA) OUT O O/O GI
1132 Fault location invalid (Flt.Loc.invalid) OUT O O/O GI
1403 >BLOCK 50BF (>BLOCK 50BF) SP O/O LED BI REL O/O GI 166 103 1 GI
1431 >50BF initiated externally (>50BF ext
SRC)
SP O/O LED BI REL O/O GI 166 104 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
