Appendix
A-54 7SJ62 Manual
C53000-G1140-C121-1
1451 50BF is switched OFF (50BF OFF) OUT O/O LED REL O/O GI 166 151 1 GI
1452 50BF is BLOCKED (50BF BLOCK) OUT O/O O/O LED REL O/O GI 166 152 1 GI
1453 50BF is ACTIVE (50BF ACTIVE) OUT O/O LED REL O/O GI 166 153 1 GI
1456 50BF (internal) PICKUP (50BF int PU) OUT O/O LED REL O/O GI 166 156 2 GI
1457 50BF (external) PICKUP (50BF ext PU) OUT O/O LED REL O/O GI 166 157 2 GI
1471 50BF TRIP (50BF TRIP) OUT O M LED REL O/O GI 160 85 2
1480 50BF (internal) TRIP (50BF int TRIP) OUT O LED REL O/O GI 166 180 2 GI
1481 50BF (external) TRIP (50BF ext TRIP) OUT O LED REL O/O GI 166 181 2 GI
Controlmode REMOTE (ModeRE-
MOTE)
IntSP O/O LED O/O GI
Control DIGSI (CntrlDIGSI) LV O/O O/O GI
Control Authority (Cntrl Auth) IntSP O/O LED O/O GI 101 85 1 GI
Controlmode LOCAL (ModeLOCAL) IntSP O/O LED O/O GI 101 86 1 GI
52 Breaker (52Breaker) CF_D12 O/O REL OM O/O GI 240 160 1 GI
52 Breaker (52Breaker) DP O/O BI OM CB O/O GI 240 160 1 GI
Disconnect Switch (Disc.Swit.) CF_D2 O/O REL OM O/O GI 240 161 1 GI
Disconnect Switch (Disc.Swit.) DP O/O BI OM CB O/O GI 240 161 1 GI
Ground Switch (GndSwit.) CF_D2 O/O REL OM O/O GI 240 164 1 GI
Ground Switch (GndSwit.) DP O/O BI OM CB O/O GI 240 164 1 GI
F# Description Type of
Informa-
tion
Log-Buffers Configurable in Matrix SCADA Interface
General IEC 60870-5-103
Event Log
Trip Log
Sens. E Log
Marked in Oscill.
Record
LED
Binary Input
Function Key
Binary Output
Event Log
Trip Log
Sens. E Log
Chatter Blocking
Status ON / OFF
General Interrogation
Type
Information-No.
Data Unit (ASDU)
General Interrogation
